الشركات المصنعه للمازربورد الخاصه با اللاب توب |
Acer :- Quanta, Inventec, Compal, Wistron.
BenQ :- Quanta.
Dell: - Quanta, Compal, Wistron, Samsung.
Fujitsu:- Siemens - Uniwill, Inventec.
HP: - Quanta, Inventec, Compal, Wistron.
Lenovo: - Quanta, Compal, Wistron.
Packard Bell: - Quanta.
Sony - Foxconn:, Quanta.
Toshiba: - Quanta, Compal, Inventec, Asus.
الآن سنرى كيفية تحديد ما هي الشركة المصنعة اللوحة الأم، وما هو الرقم الخاص بها
Quanta. In the schematic indicates the three digit code, but on the motherboard code have 11 characters. For example code on the motherboard DA0AT8MB8H6 (always starts with DA0), discarding the first three characters and the last five we have a number of schemes AT8.
رمز المازر بورد من نوع Quanta لديها 11 حرفا. لرمز على سبيل المثال DA0AT8MB8H6 اللوحة الأم (يبدأ دائما مع DA0)، ونبذ الأحرف الثلاثة الأولى وآخر خمسة لدينا عدد من الخطط AT8.
Inventec - markings on the motherboard 6050A2250501 (always starts with the 6050A), the schematic Doc number 1310A2250501.
Uniwill (ECS) has a project code in the form S50IA0, L53II0, 258SA0 and so on. Also on the motherboard is the part number (for L53II0 is 37GL53010-01, always starts with 37), but it is not always present in the schematic diagram.
Inventec - علامات على االمازربورد 6050A2250501 (يبدأ دائما مع 6050A)، والرقم التخطيطي 1310A2250501.
UNIWILL (ECS) يحتوي على رمز المشروع في شكل S50IA0، L53II0، 258SA0 على اللوحة الأم هو رقم الجزء (لL53II0 هو 37GL53010-01، يبدأ دائما مع 37)، ولكنها ليست دائما موجودة في الرسم التخطيطي.
Foxconn. Motherboards prodused for Sony have two codes, one is Sony code - MBX-178, second is Foxconn code - M620. In the scheme there is always a code Foxconn, but may not have Sony code.
Asus. Laptop model number corresponds to the number scheme for the rare exception
فوكسكون. prodused لسوني واثنين من الرموز، واحد هو رمز سوني - MBX-178، الثاني هو رمز فوكسكون - M620. في مخطط هناك دائما رمز فوكسكون، ولكن قد لا يكون رمز سوني.
اسوس. رقم طراز اللاب توب يتوافق مع مخطط رقم للاستثناء نادر.
Compal. Project number similar on the schematic diagram and on the motherboard LA-3301P, LA-3581, LA-5831P, and so on.
Wistron mark their schemes as words (Monarch, Mocha, Homa), and codes (Y4A, LWG2, JM70-MV). But apart from that on the motherboard indicates the number of 48.4s901.011 (Leopard), which always starts at 48, while on the scheme in addition to the name indicates the number of project
91.4s901.001 (always starts at 91). As we see the middle parts of numbers (4s901) are identical.
